Best 200W GaN Chargers

Multiple ports charger for laptops and mobile devices

The mini 200W GaN chargers in this review can deliver up to 100W in power delivery mode using two USB-C ports concurrently. A single, small and lightweight adapter be used to power up to two 100W notebooks, and makes all 100W notebook power adapters a thing of the past.

Let’s look at the best 200W GaN chargers currently available in the market.

Chargeasap Omega 200W GaN Charger

Chargeasap GaN Charger
Chargeasap GaN Charger
DescriptionTechnical Specifications
Size88 x 55 x 42mm (203.3cm3)
Weight220 grams
Ports2 x USB-C and 2 x USB-A
Total Max. Wattage200W

The Chargeasap Omega 200W GaN charger was promoted as the World’s Smallest 200W adapter, and it has received a total of US$3.39million from 33,910 backers from Indiegogo and Kickstarter. After reviewing with the other brands, we find that it might not be the smallest in size, but it is the lightest by at least 29% compared to the next heaviest 200W charger. The weight is about the same as some of the larger smartphones in the market now.

Chargeasap Omega 200W Charger 2-Pin Prong
Chargeasap Omega 200W Charger 2-Pin Prong

When using only the two USB-C ports, the maximum power output for each port is 100W concurrent.  This is the only configuration when the charger delivers the full 200W output in total.

USB-C 1USB-C 2
100W100W

If you add another USB-A, then the second USB-C port drops to 65W, while the USB-A 1 delivers up to 22.5W. The total power output drops to 187.5W.

USB-C 1USB-C 2USB-A 1
100W65W22.5W

Lastly, when using all four USB-C ports concurrently, only the first USB-C port is 100W, while the second USB-C port drops to 65W. The remaining USB-A ports in this mode have 12W output each. The total power output drops to 189W.

USB-C 1USB-C 2USB-A 1USB-A 2
100W65W12W12W

For other output configurations, please check out our review on Chargeasap Omega 200W here.

Volta Giga 200W GaN Charger

Volta Giga 200W GaN
Volta Giga 200W GaN
DescriptionTechnical Specifications
Size84 × 68.2 x 36mm (206.2cm3)
Weight310 grams
Ports3 x USB-C and 1 x USB-A
Total Max. Wattage200W

The Volta Giga 200W GaN Charger is another strong contender based on the specifications with sizes that are quite close to the Chargeasap Omega. The biggest disadvantage is the weight of 310 grams which is almost 29% heavier than the Omega.

Even though the Volta Giga 200W GaN’s design has 3 USB-C ports, the third USB-C power output has a significantly lower power output when compared to the first two USB-C ports. In fact, it is just slightly better than the USB-A for the Chargeasap. The only advantage is perhaps that you can use a new USB-C to USB-C cable which will be replacing the old USB-A cables.

Like the Chargeasap Omega, when using only the two USB-C ports, each port can deliver up to 100W concurrently. This is the only configuration when the charger delivers the full 200W output.

USB-C 1USB-C 2
100W100W

If you add another USB-A, then the second USB-C port drops to 65W, while the USB-A 1 delivers up to 22.5W. The total power output is now 195W.

USB-C 1USB-C 2USB-C 3
100W65W30W

Lastly, when using all four USB-C ports concurrently, only the first USB-C port is 100W, while the second USB-C port drops to 65W. The remaining USB-A ports in this mode have 12W output each, and the total power output from the charger is now 190W.

USB-C 1USB-C 2USB-C 3 and USB-A
100W65W25W combined

Thundergo 200W GaN Charger



DescriptionTechnical Specifications
Size83 x 63 x 35mm (183cm3)
Weight320 grams
Ports3 x USB-C and 1 x USB-A
Total Max. Wattage200W

The Thundergo 200W GaN Charger is the smallest in our review at only 183cm3 in size, which is about 9% smaller than the Chargeasap Omega 200W GaN Charger. However, it is also the heaviest of the lot at 320 grams. The design of the port configuration is similar to the Volta Giga with 3 x USB-C and 1 x USB-A. The power output is quite similar for the above-mentioned configurations, but there are still subtle differences that are negligible.

Like the other 200W charges, each USB-C port can deliver up to 100W concurrently when only the first two ports are in use. This is the only configuration when the charger delivers the full 200W output.

USB-C 1USB-C 2
100W100W

If you add another USB-A, then the second USB-C port drops to 65W, while the USB-A 1 delivers up to 22.5W. The total power output is now 195W.

USB-C 1USB-C 2USB-C 3
100W65W30W

Lastly, when using all four USB-C ports concurrently, only the first USB-C port is 100W, while the second USB-C port drops to 65W. The remaining USB-A ports in this mode have 12W output each, and the total power output from the charger is now 190W.

USB-C 1USB-C 2USB-C 3 and USB-A
100W65W25W combined
